Huawei Honor 6x Rear Camera Replacement

Written By: M Morgan

Comments: 1

Difficulty

Moderate

Steps

Time Required

40 - 45 minutes

Introduction

If the camera of your Huawei Honor 6x is inoperable and the problem is not due to a cracked cover, the rear camera will need to be replaced. Removing the broken camera assembly is simple and easy after opening the phone.

Tools

Step 1

Turn off the device.

Step 2

Insert the SIM Card Eject Tool into the SIM card tray hole.
Press the eject tool into the hole until the tray clicks open.

Step 3

Remove the SIM tray from the device using two fingers.
When reinserting the SIM card, be sure it is properly aligned with the SIM tray.

Step 4

Remove the SIM card from the compartment using two fingers.

Step 5

Insert a plastic opening tool into the Micro USB charging port with the the angled side of the tool facing the screen.
Pry the screen off the back of the phone by pushing down on the opening tool.

Step 6

Slide the opening tool or spudger along the bottom of the phone and around the edge.

Step 7

Once three sides of the screen are detached, pry the phone apart using two hands.
When separating the back panel from the screen, do not pull them too far apart. There is an interconnect that is attached to both sides that could break, or tear, if pulled too far.
