Introduction
Use this guide to replace the battery in your Lenovo ThinkPad T490s Laptop.
For your safety, discharge the battery below 25% before disassembling your device. This reduces the risk of fire if the battery is accidentally damaged during the repair. If your battery is swollen, take appropriate precautions.
-
-
Orient your laptop so that the screen's silver hinges are closest to you.
-
Insert an opening pick between the back cover and the device body near a hinge corner.
-
Pry upward to release the clips holding the cover. Listen for a loud click when each clip releases.
-
-
-
Insert your opening pick between the cover and the device body at the other hinge corner.
-
Pry upward to release additional retaining clips.
-
-
-
Grab the battery pull-tab at the head of the connector.
-
Pull the connector out of its socket in the direction of the cable.
-
To reassemble your device, follow these instructions in reverse order.
For optimal performance, calibrate your newly installed battery after completing this guide.
Take your e-waste to an R2 or e-Stewards certified recycler.
Repair didn’t go as planned? Try some basic troubleshooting, or ask our Answers community for help.
